PR Electronics 5331A3B Programmable Temperature Transmitter
신제품
재고 있음7 단위즉시 배송 가능
온도 트랜스미터 PR Electronics 5331A3B Pt100 RTD 센서용 2선 프로그래머블 트랜스미터, 0“200°C 범위, 7.2“35 VDC 전원, 1500 VAC 갈바닉 절연 및 위험 구역 인증.
25331A3BAtexElectronicsGalvanicIECExIndustrialIP68IsolatedModulePRprogrammablePt100RTDSensorTemperatureTransmitterwire
방대한 재고
글로벌 배송
전문 지원
품질 보장
PR Electronics 5331A3B 2-Wire Programmable Transmitter
The PR Electronics 5331A3B is a 2-wire programmable temperature transmitter designed for Pt100 RTD sensor applications. Engineered for industrial process control environments, it provides stable signal transmission, high accuracy signal dynamics, and multiple international hazardous area certifications.
Manufacturer: PR electronics
Type: 2-wire programmable transmitter
Model: 5331A3B
PO No.: 1358532
Serial No.: 211521009
LB. Rev: 5331S013
Version: A
EAC Ex Approved
CSA / cUS Certified
DNV-GL Approved
| Sensor Type | Pt100 RTD |
| Temperature Range | 0 / 200°C |
| Supply Voltage | 7.2...35 VDC |
| Voltage Drop | 7.2 VDC |
| Galvanic Isolation | 1500 VAC |
| Isolation Voltage (Test / Operation) | 1.5 kVAC / 50 VAC |
| Ambient Temperature | -40 to +85°C |
| Protection Degree | IP68 / IP00 |
| Dimensions | 44 x 20.2 mm |
| Warm-up Time | 5 min |
| Programming | Loop Link |
| Signal / Noise Ratio | Min. 60 dB |
| Response Time (Programmable) | 1...60 s |
| EEPROM Error Check | 3.5 s |
| Signal Dynamics (Input) | 20 bit |
| Signal Dynamics (Output) | 16 bit |
| Max. Wire Size | 1 x 1.5 mm² stranded wire |
| Screw Terminal Torque | 0.4 Nm |
| Vibration Standard | IEC 60068-2-6 |
| IECEx Certification | IECEx DEK 13.0035X |
| ATEX / Ex Marking | KEMA 10ATEX0003X |
