Schneider XAC-B04 Empty Pendant Control Station
신제품
재고 있음1 단위즉시 배송 가능
펜던트 제어 스테이션 SCHNEIDER Harmony XAC-B04 4개의 컷아웃이 있는 빈 펜던트 제어 스테이션, IP65 보호 등급, 유리 강화 폴리에스터 인클로저 및 산업 제어 응용 분야를 위한 넓은 작동 온도 범위.
4CertifiedControlCSACutDoubleEEmptyenclosureGlassHarmonyIndustrialInsulatedIP65outPendantpolyesterreinforcedSchneiderStationXACXAC-B04Yellow
방대한 재고
글로벌 배송
전문 지원
품질 보장
SCHNEIDER XAC-B04 Empty Pendant Control Station
The SCHNEIDER XAC-B04 is an empty pendant control station from the Harmony XAC range, designed for industrial power and control circuit applications. This double-insulated enclosure is manufactured from glass reinforced polyester and provides high protection levels for demanding environments.
Manufacturer: SCHNEIDER
Type: Empty Pendant Control Station
Model: XAC-B04
Range Of Product: Harmony XAC
Product Or Component Type: Pendant Control Station
Device Short Name: XACB
| Control Station Type | Double Insulated |
| Enclosure Material | Glass Reinforced Polyester |
| Electrical Circuit Type | Power Circuit / Control Circuit |
| Enclosure Type | Empty Enclosure |
| Number Of Cut-Out | 4 Cut-Outs |
| Control Station Colour | Yellow |
| Cable Entry | Rubber Sleeve With Stepped Entry 10 / 22 mm |
| Guard Rail | Without |
| Vertical Operator Cut-Out Centre | 40 mm |
| Standards | CSA C22.2 No 14 / IEC/EN 60947-5-1 / IEC/EN 60947-3 |
| Product Certifications | CSA Type 4 |
| Protective Treatment | TH |
| Ambient Air Temperature For Operation | -25 / 70 °C |
| Ambient Air Temperature For Storage | -40 / 70 °C |
| Vibration Resistance | 15 gn (f= 10 / 500 Hz) Conforming To IEC 60068-2-6 |
| Shock Resistance | 100 gn Conforming To IEC 60068-2-27 |
| Overvoltage Category | Class II Conforming To IEC 61140 |
| IP Degree Of Protection | IP65 Conforming To IEC 60529 |
| IK Degree Of Protection | IK08 Conforming To IEC 62262 |
