Schunk OSE-B22-0 Swivel Head
중고
재고 있음1 단위즉시 배송 가능
Swivel Head
The Schunk OSE-B22-0 swivel head offers a 0-180° swivel angle, 1.5 Nm torque, and 0.2 s cycle time, providing precise and reliable motion control for automation applications.0-180°1.5ActuatorAngleAutomationControlCycleFastHeadhigh-performanceIndustrialMotionNmOSE-B22-0PositioningPreciseSchunkSwivelTorqueUnit
방대한 재고
글로벌 배송
전문 지원
품질 보장
Schunk OSE-B22-0 Swivel Head
The Schunk OSE-B22-0 Swivel Head is designed for precision positioning applications, providing a reliable and efficient solution for automated systems. With a 0-180° swivel angle and a fast cycle time of 0.2 seconds, it ensures smooth and controlled motion.
Manufacturer: Schunk
Type: SWIVEL HEAD
Model: OSE-B22-0
Part No.: 354210
With its precise motion capabilities and compact design, this swivel head is ideal for automation tasks requiring controlled and repeatable angular movements.
| Swivel Angle | 0 - 180° |
| Number of Feed-Throughs | 0 |
| Torque at 6 Bar | 1.5 Nm |
| Cycle Time | 0.2 s |
| Operating Pressure Range | 4.5 to 8 bar |
| Operating Temperature Range | 5 °C to 60 °C |
