Belimo BFL24-T Spring-Return Actuator

Manufacture: Belimo
Type: Spring-return actuator
Model: BFL24T

Torque motor: 4 Nm
Torque fail-safe: 3 Nm
Nominal voltage: 24 V AC/DC (19.2 … 28.8 V AC / 21.6 … 28.8 V DC)
Nominal voltage frequency: 50/60 Hz
Power consumption in operation: 2.5 W
Power consumption in rest position: 0.8 W
Power consumption for wire sizing: 4 VA
Auxiliary switch: 2x SPDT
Switching capacity auxiliary switch: 1 mA … 3 A (0.5 A inductive), DC 5 V … AC 250 V
Angle of rotation max.: 95°
Running time motor: <60 s / 90°
Running time fail-safe: 20 s
Degree of protection: IP54
Ambient temperature: -30 … 55°C
Dimensions: 48 x 80 x 180 mm
Attachment:
BELIMO 1123974-2434 THERMOELECTRIC TRIPPING DEVICE
Manufacture: Belimo
Type: Thermoelectric Tripping Device
Model: 11239742434
