Eaton EASY-E4-UC-16RE1 I/O Expansion Module
| Manufacture | Eaton |
| Rated insulation voltage (Ui) | 240 V |
| Rated operational voltage | 20.4 … 26.4 V AC , 10.2 … 14.4 V DC, 20.4 … 28.8 V DC, 12/24 V DC, 24 V AC |
| Input frequency | 50/60 Hz |
| Input current | 3.3 mA |
| Power consumption | 3 W |
| Switching current | 5 A |
| Rated impulse withstand voltage (Uimp) | 6 kV |
| Connection type | Screw terminal |
| No. of digital inputs (DI) | 8 |
| No. of digital outputs (DO) | 8 Relay Output (Normally open) |
| Tightening torque | 0.6 Nm, Screw terminals |
| Mounting position | Vertical, Horizontal |
| Protection degree | IP20 |
| Ambient Operating temperature | -25 … 55°C |
| Dimensions | 58 x 90 x 72 mm |
| Condition | Used |
| SKU | 1027891 |
| Weight | 0,26 |
