Endress+Hauser EC 17 Z Electronic Insert
133,33$
De Endress+Hauser Elektronische Inzet (Model: EC17Z, Onderdeelnummer: 7701844) sluit aan op de FTC 380/1/2Z en FTC 480/1/2Z, en biedt goedkeuringen voor gebruik in explosiegevaarlijke gebieden en betrouwbare signaaloverdracht via pulsfreqentiemodulatie (PFM) met een breed temperatuurbereik (-25 tot +100°C).
Endress+Hauser Electronic Insert (Model: EC17Z)
The Endress+Hauser Electronic Insert (Model: EC17Z) is designed for use with the FTC 380/1/2Z and FTC 480/1/2Z. It features approvals for use in explosion hazardous areas (EEx ia, FM IS, CSA IS) and provides reliable signal transmission over a wide temperature range. It connects to devices like the Nivotester, Silometer, or Prolevel via standard screened installation cable.
- Manufacturer: Endress+Hauser
- Type: Electronic Insert
- Model: EC17Z
- Part No.: 7701844
- CAN Used with: FTC 380/1/2Z, FTC 480/1/2Z
- Approval for Explosion Hazardous Areas: EEx ia, FM IS, CSA IS
- Connection: Nivotester, Silometer, Prolevel over standard screened installation cable
- Temperature Range: Wide temperature range
Electrical Information
- Supply Voltage: approx. 10.5 / 12.2 V
- Basic Current: approx. 4 / 10 mA
- Operating Frequency: approx. 300 kHz
- Housing: Plastic, potted electronics
- Protection Type: Electronics IP 55, terminals IP 00
- Signal Transmission: Pulse-frequency-modulation (PFM)
- Pulse Current: approx. 10 mA / 18 mA
- Pulse Width: approx. 200 µs
- Transmission Frequency: 185 / 116 Hz, equivalent to 20 pF / 350 pF
- Permissible Ambient Temperature: -25 / +100°C
