Leuze Electronic VBT-50-1950.4000 / IVBR/4-50-1950-03,4000 Safety Light Curtain Receiver/Transmitter
766,66$
Veiligheidslichtgordijn LEUZE ELECTRONIC VARIO veiligheidslichtgordijn-set met een beschermhoogte van 1950 mm, 40 stralen, 50 mm tussenafstand en 24 V DC werking, ontworpen voor industriële machinebeveiliging.
LEUZE ELECTRONIC IVBR/4-50-1950-3.400 Safety Light Curtain
The LEUZE ELECTRONIC VARIO series safety light curtain (receiver and transmitter set) is designed for reliable machine safeguarding and personnel protection in industrial automation environments. With precise infrared LED technology and a 1,950 mm protection height, it ensures dependable detection and safety monitoring in hazardous areas.
Manufacturer: LEUZE ELECTRONIC
Type: Safety Light Curtain Receiver / Transmitter
Receiver Model: IVBR/4-50-1950-3.400
Transmitter Model: IVBR/4-50-1950-03,4000
Order No.: 50107958 / 50107958-03
Serial No.: 1312530 / 1312531
| Series | VARIO |
| Beam Spacing | 50 mm |
| Number of Beams | 40 |
| Protection Height | 1,950 mm |
| Operating Range | 0.7 ... 5 m |
| Light Source | LED, Infrared |
| Output Type | Digital Switching Output |
| Switching Device | Transistor, PNP |
| Switching Principle | Dark Switching |
| Supply Voltage | 24 V DC |
| Current Consumption (Max.) | 40 mA |
| Output | PNP / NPN (Push-Pull) |
| Output Logic | NO / NC Selectable |
| Material | Aluminum |
| Connection Type | Cable 4 m, 3-wires |
| Protection Class | IP54 |
| Ambient Temperature | -10 ... 40 °C |
| Dimensions | 10 x 2,160 x 27 mm |
