Lumberg 0911 ANC 101 Passive Branch Module

Manufacturer: LUMBERG

Type: PASSIVE BRANCH MODULE / Circular Metric Connector

Model: M8309-01 / PAAS

Part No.: 0911 ANC 101

Product Family: ASi

Actuator Supply Voltage (Nominal): 24 V DC

Actuator Supply Voltage (Range): 10 V DC to 30 V DC

I/O Connection: M12, 5-poles, A-coded

Housing Material: Plastic, PA

Housing Color: Black

Fastening Torque (I/O Connection): M12: 0.5 Nm

Contact Base Material: CuZn

Degree of Protection: IP65

Dimensions (W x H x D): 55 mm x 32.5 mm x 64 mm

Ambient Temperature (Operation): -25 °C to 80 °C

The LUMBERG M8309-01 / PAAS is a robust passive branch module designed for reliable and efficient I/O distribution in ASi industrial environments. With a durable plastic housing, IP65 protection rating, and a 24 V DC nominal supply, it ensures dependable operation even in demanding conditions. Its compact design and M12 A-coded connection interface make it ideal for modern industrial automation systems.
