Pepperl+Fuchs NRB5-18GM50-E2-C-V1 Inductive Sensor
Inductieve sensor De Pepperl+Fuchs NRB5-18GM50-E2-C-V1 inductieve sensor biedt een detectiebereik van 5 mm, PNP normaal open uitgang, en IP67 bescherming voor industriële toepassingen.
Pepperl+Fuchs NRB5-18GM50-E2-C-V1 Inductive Sensor
The Pepperl+Fuchs NRB5-18GM50-E2-C-V1 Inductive Sensor is designed for precise and reliable object detection in industrial applications. With a durable brass housing, IP67 protection, and PNP normally open switching output, this sensor ensures stable performance even in demanding environments.
Manufacturer: Pepperl+Fuchs
Type: Inductive Sensor
Model: NRB5-18GM50-E2-C-V1
Part No.: 187799
| Sensing Range | 5 mm |
| Reduction Factor | 1 |
| Assured Operating Distance | 0 to 4.05 mm |
| Operating Voltage | 10 to 30 V DC |
| Operating Current | 200 mA |
| Switching Output | Normally Open |
| Output Type | PNP |
| Threading | Connector Plug M12 x 1, 4-Pin |
| Housing Material | Brass, PTFE Coated |
| Operating Temperature | -25 to 70°C |
| Degree of Protection | IP67 |
