Vega Vegapuls 62 Radar Level Sensor

Name: VEGA VEGAPULS 62 RADAR LEVEL SENSOR
SKU: 1056606
Price: 622.22 USD
Availability: InStock

vega-VEGAPULS-62-radar-level-sensor-(new)

vega-VEGAPULS-62-radar-level-sensor-(new)-1

vega-VEGAPULS-62-radar-level-sensor-(new)-2

vega-VEGAPULS-62-radar-level-sensor-(new)-3

vega-VEGAPULS-62-radar-level-sensor-(new)-4

vega-VEGAPULS-62-radar-level-sensor-(new)-5

vega-VEGAPULS-62-radar-level-sensor-(new)-6

vega-VEGAPULS-62-radar-level-sensor-(new)-7

vega-VEGAPULS-62-radar-level-sensor-(new)-8

vega-VEGAPULS-62-radar-level-sensor-(new)-9

Nieuw

Op voorraad1 eenheidKlaar voor verzending

622,22$

Radar Sensor for Continuous Level Measurement

The Vega VEGAPULS62 radar sensor provides continuous level measurement for liquids, featuring a 35 m measurement range, high protection rating, and wide process temperature and pressure capabilities. Ideal for extreme industrial applications with reliable performance in harsh environments.

Fabrikant

VEGA

SKU

1056606

Categorie

Transmitter

Staat

Nieuw

35 comas Continuous Industrial IP66 Level Liquid M Measurement Radar Range Sensor Vega VEGAPULS62

Enorme Voorraad

Wereldwijde verzending

Deskundige Ondersteuning

Kwaliteit Gegarandeerd

Vega VEGAPULS62 “ Radar Sensor for Continuous Level Measurement of Liquids

The Vega VEGAPULS62 is a high-precision radar sensor designed for continuous level measurement of liquids in challenging environments. With advanced features like a wide measurement range and robust housing materials, it ensures reliable performance in extreme conditions, from -196°C to 450°C and pressures up to 40 bar.

Manufacturer: Vega

Type: Radar Sensor for Continuous Level Measurement of Liquids

Model: VEGAPULS62

MNR: PS62.XXCFC2HAMXX

ID. No.: 060PS60XK1 IC / 3892A-PS616263

Order No.: 1968848/003

HW version: 2.1.0

SW version: 4.5.1

Flange Ring Part No.: 301011

Ring, Flange No.: CH 336057 (2.36218) CH 900051

Measuring Distance Range	35 m
Operating Voltage	9.6 to 36 V DC
Process Temperature	-196 to 450°C
Process Pressure	-1 to 40 bar
Output	Two-wire: 4 to 20 mA/HART
Frequency	26 GHz
Beam Angle	Bigger than 3°
Threaded Connection	G1½, 1½ NPT
Flange Connection	DN50, 2
Seal Material	FKM, FFKM, Graphite and Ceramic
Housing Material	Plastic, Aluminum, Stainless Steel (Precision Casting), Stainless Steel (Electropolished)
Protection Rating	IP66/IP68
Ambient Temperature	-40 to 80 °C
Surface Finish	SSH1
Nominal Flange Pressure (PN40)	40 bar
Nominal Flange Diameter (DIN2501, DN50)	50 mm
Flange Ring Material (1.4404 316L)	Stainless Steel
