Alfa Electric THR2 Thermostat
New
Available on request
Thermostat
A compact DIN-rail mounted industrial thermostat designed for precise temperature control and protection of electrical panels and automation systems.AlfaAutomationComponentsControlDINElectricElectricalenclosureIndustrialPanelrailTemperaturethermostatTHR2
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Alfa Electric THR2 Thermostat
A compact and reliable industrial thermostat designed for precise temperature control in electrical panels and automation systems. The THR2 thermostat ensures safe and stable operation of electrical equipment by regulating internal enclosure temperature. Manufacturer: Alfa Electric
Type: Thermostat
Model: THR2
Item No.: E348803
| Output Configuration | NC |
| Contact Type | Snap Action |
| Max. Operating Current | 10 A |
| Max. Operating Voltage | 250 V AC |
| Electrical Connections | 2-pole terminal for 2.5 mm² wire |
| Connection | Screw terminals |
| Mounting | DIN rail mounting |
| Temperature Control Range | 0 / 60 °C |
| Operating Temperature | -25 °C to +80 °C |
| Casing | PA6, UL94 V0 self-extinguishing, light grey RAL 7035 |
| Protection Degree | IP20 (EN 60529) |
| Dimensions (H x W x D) | 61 x 34 x 35 mm |
