Alfa Electric THRV22 Double-Thermostats
New
In stock28 unitsReady to ship
Double Thermostat The Alfa Electric THRV22 double thermostat features one normally open and one normally closed contact for independent control of heating and cooling devices. Designed for DIN rail installation, it offers snap-action switching, IP20 protection, and reliable temperature control for electrical enclosures and industrial control panels.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
| Contacts | 1NO (blue), 1NC (red) |
| Voltage | (NO: 250 VAC), (NC: 250 VAC) |
| Current | (NO: 10(1,6) A), (NC: 10A) |
| Power | 30 W |
| Contact type | Snap action |
| Contact resistance | max. 10 mOhm |
| Electrical connections | 2-pole terminal for 2.5 mm² wire |
| Mounting | Clip for mounting on DIN rail 35 mm EN50022 |
| Installation position | Variable |
| Protection degree | IP20 |
| Operating temperature | -25 to +80 °C |
| Dimensions HxWxD | 61x53x35 mm |
| Condition | New |
| Stock key | JO-004 |
| SKU | 1093408 |
| Weight | 0,09 |
