Balluff BOS 18K-UU-1XA-E5-C-S4 Optoelectronic Sensor
New
In stock3 unitsReady to ship
Optoelectronic Sensor
The Balluff BOS 18K-UU-1XA-E5-C-S4 sensor ensures accurate object detection using red laser light with 100 mm sensing range, 10“30 VDC supply, and IP67 protection for industrial applications.100mm18K-UU18K-UU-1XA-E5-C-S4BalluffBOSConnectorIndustrialIP67laserM12NOOpticalOptoelectronicPNPRangeRedRetroreflectiveSensingSensor
Used
In stock 39,99$
This product is also available used
View Used Version →
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Balluff BOS18K-UU-1XA-E5-C-S4 Optoelectronic Sensor
The Balluff BOS18KUU1XAE5CS4 Optoelectronic Sensor is a high-precision retroreflective sensor designed for reliable object detection using red laser light. It ensures accurate performance, compact design, and high protection level, making it suitable for demanding industrial environments.
Manufacturer: Balluff
Type: Optoelectronic Sensor
MNR: BOS 18K-UU-1XA-E5-C-S4
| Sensing Range | 100 mm |
| Load Capacitance Max. at Ue | 1 mF |
| No-load Current Io Max. at Ue | 35 mA |
| Operating Voltage Ub | 10 / 30 VDC |
| Rated Insulation Voltage Ui | 75 V DC |
| Rated Operating Current Ie | 100 mA |
| Connection Method | Connector, M12x1-Male, 4-pin |
| Electrical Design | PNP |
| Contact | Normally Open (NO) |
| No. of Pins | 4 Pins |
| Optical Principle | Retroreflective Sensor |
| Switching Function | Dark-on |
| Housing Material | ABS |
| Ambient Light Max | 5000 Lux |
| Wavelength | 650 nm |
| Average Power Po Max. | 390 µW |
| Light Type | Laser Red Light |
| Protection Degree | IP67 |
| Length, Diameter | 86.8 x 18 mm |
