Balluff BTL5-E17-M0150-P-S32 Micropulse Transducer
Used
In stock1 unitReady to ship
Micropulse Transducer
A high-accuracy analog position transducer offering stable linear measurement, durable construction, and reliable performance for industrial automation systems.150AnalogAutomationBalluffBTL035MBTL5-E17-M0150-P-S32IndustrialIP67LinearMicropulsemmPositionSensorStrokeTransducer
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Balluff BTL5-E17-M0150-P-S32 Micropulse Transducer
A high-precision analog micropulse transducer designed for accurate, reliable linear position measurement in industrial automation systems. Built for harsh environments and long service life, this sensor delivers stable output performance and dependable signal integrity. Manufacturer: BALLUFF
Type: Micropulse Transducer
Model: BTL5-E17-M0150-P-S32
Order Code: BTL035M
Part No.: 084435324 HU
Mechanical Attributes
Approvals / Conformity
| Version | Type P |
| Null Point | 73.0 mm |
| Connection Type | Connector |
| Current Draw (at 24 V DC) | ‰¤ 150 mA |
| Error Signal Ia Falling | ‰¤ 3.2 mA |
| Error Signal Ua Falling | < 0 V |
| Error Signal Ua Rising | ‰¥ 10.2 V |
| Dynamic Loop Applications | No |
| Inrush Current | ‰¤ 3 A / 0.5 ms |
| Interface | Analog Interface, Current |
| Interface Group | Analog |
| Load Resistance (RL max.) | ‰¤ 500 Ohm |
| Non-Linearity Max. | ±100 µm |
| Number of Magnets Max. | 1 ST |
| Operating Voltage Max. | 28.0 V DC |
| Operating Voltage Min. | 20.0 V DC |
| Output Signal | 20 / 4 mA |
| Ripple | 0.5 Vpp |
| Voltage Resistance (GND “ Housing) | 500 V DC |
| Nominal Stroke | 150 mm |
| Ambient Temperature Max. | 85 °C |
| Ambient Temperature Min. | -40 °C |
| Cable/Connector Out | Axial |
| Connector Type | M16 |
| Housing Material | Aluminum, Anodized |
| No. of Poles | 8 |
| Certifications | CE, cURus |
| Enclosure Rating | IP67 (with connector) |
| Generation | Generation 5 |
| No. of Magnets (Factory Setting) | 1 ST |
