Beckhoff EL2252 Ethercat Terminal
New
In stock1 unitReady to ship
EtherCAT Terminal Beckhoff EL2252 EtherCAT, 24 V DC operation, and compact DIN rail mounting for industrial automation applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
| Ser.Nr . | 44230013 |
| Rev.Nr . | 0020 |
| Connection technology | 4-wire |
| No. of digital output | 2 |
| Nominal Voltage | 24 vdc |
| Load type | resistive, inductive, lamp load |
| Timestamp accuracy | 10 ns between the channels |
| Timestamp resolution | 1 ns |
| Distributed clocks | yes |
| Distributed clock accuracy | 1 µs |
| Output delay through 24 V power section | typ. < 1 µs |
| Max. output current | 0.5 A (short-circuit proof) per channel |
| Output stage | push-pull |
| Short-circuit current | typ. 4 A/150 µs |
| Current limitation | typ. 1.5 A |
| Switching-off energy | 150 mJ/channel |
| Switching times | typ. TON: < 1 µs, typ. TOFF: < 1 µs |
| Current consumption E-bus | typ. 130 mA |
| Current consumption power contacts | typ. 30 mA + load |
| Bit width in the process image | 8 bit output (ch. 1 + ch. 2), 9 byte timestamp |
| Electrical isolation | 500 V (E-bus/field potential) |
| Special features | Timestamp, outputs can be connected in high-resistance mode, short-circuit proof. |
| Operating temperature | 0…55°C |
| Relative humidity | 95%, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission conforms to | EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP20/variable |
| Pluggable wiring level | for all ESxxxx terminals |
| Approvals/markings | CE, CCC, UL, ATEX, IECEx, cFMus |
| Ex marking ATEX | II 3G Ex ec IIC T4 Gc,IECEx:Ex ec IIC T4 Gc |
| cFMus | Class I, Division 2, Groups A, B, C, D |
| Material | polycarbonate |
| Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Side by side mounting by means of | double slot and key connection |
| Marking labeling of the | BZxxxx series |
| Dimensions | 12 x 100 x 68 mm |
| Stock key | CON003 |
| Condition | New |
| SKU | 1101448 |
| Weight | 0,05 |
