Brueninghaus Hydromatik A2FM80/61W-PPB03 Axial Piston Fixed Motor

Manufacturer: BRUENINGHAUS HYDROMATIK / Rexroth

Type: Axial Piston Fixed Motor

Model: A2FM80/61W-PPB03

Size: 80

Displacement: 80.4 cm³

Mounting Flange: ISO 3019-2 4-hole

Direction of Rotation: Viewed on drive shaft, bidirectional

Pressure Max: 450 bar

Speed: 4500…5000 rpm

Shaft Diameter: 35 mm

Flow Rate: 362 l/m

Torque at 400 bar: 512 Nm

Viscosity Range: 16 ….  36 mm²/s

Weight: 25.7 Kg
