Eaton FAZ-S1/2 Miniature Circuit Breaker
New
In stock1 unitReady to ship
Miniature Circuit Breaker 2-pole EATON miniature circuit breaker with 1 A rated current, S tripping characteristic, and 10 kA switching capacity, designed for reliable electrical circuit protection.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
| Part No. | 278805 |
| Product range | FAZ |
| Number of poles | 2 |
| Tripping characteristic | S |
| Rated current | 1 A |
| Rated operational voltage | 240/415 VAC, 60 VDC |
| Rated insulation voltage | 440V |
| Rated switching capacity (Icu) | 10 kA |
| Rated short-circuit breaking capacity Icn at 400 V | (IEC 60947-2: 10 kA), (EN 60898: 0 kA) |
| Frequency | 50 – 60 Hz |
| Mounting width per pole | 17,5 mm |
| Enclosure height | 80 mm |
| Degree of Protection | IP20, IP40 |
| Operating ambient temperature | -40 to 75 °C |
| Condition | New |
| Stock key | JO-004 |
| SKU | 1093873 |
| Weight | 0,29 |
