FAG 53222 Axial Deep Groove Ball Bearing
New
In stock3 unitsReady to ship
AXIAL DEEP GROOVE BALL BEARING
FAG 53222 Axial Deep Groove Ball Bearing with 110 mm inner diameter, 160 mm outer diameter, and 40.2 mm height. Steel sheet metal cage, high load capacity, and wide operating temperature range.1“1016053222AxialBallbearingCageCapacityDeepdiameterFagGrooveHighIndustrialInnerLoadmmOuterPrecisionSteelThrust
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 53222 AXIAL DEEP GROOVE BALL BEARING
The FAG 53222 Axial Deep Groove Ball Bearing is built for high axial load capacity and reliable performance in industrial applications. With precision-engineered components and a steel sheet metal cage, it offers excellent durability and smooth operation under demanding conditions.
Manufacturer: FAG
Type: Axial Deep Groove Ball Bearing
Model: 53222
| Inner Diameter Shaft Washer (d) | 110 mm |
| Outer Diameter Housing Washer (D) | 160 mm |
| Height (T) | 40.2 mm |
| Outer Diameter Shaft Washer (d1) | 160 mm |
| Minimum Chamfer Dimension (rmin) | 1.1 mm |
| Dynamic Load Rating (Ca) | 126,000 N |
| Static Load Rating (C0a) | 365,000 N |
| Fatigue Load Rating (Cua) | 14,400 N |
| Limiting Speed | 2,650 1/min |
| Reference Speed | 3,250 1/min |
| Cage | Steel Sheet Metal |
| Operating Temperature | -30 to +150 °C |
