Faulhaber 3557K024CS 171 DC Micromotor
New
In stock1 unitReady to ship
DC Motor With Gearhead
Faulhaber 3557K024CS 171 DC motor, 24 VDC, 25.4 W, 5500 rpm, integrated with 3.71:1 precision planetary gearhead for compact and high-efficiency motion control systems.17:124v35573557K024CSAutomationCompactdcDriveFaulhaberGearboxGearheadIndustrialKMotionmotorPlanetaryPrecisionRoboticsSeriesWith
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Faulhaber 3557K024CS 171 DC Motor With Gearhead
The Faulhaber 3557K024CS 171 is a high-performance DC motor from Series 3557 K, equipped with a precision planetary gearhead for controlled torque transmission and compact drive solutions.
Manufacturer: Faulhaber
Type: DC Motor with Gearhead
Model: 3557K024CS 171
Series: 3557 K
Gearhead Information
Recommended for robotics, precision automation systems, medical devices, and compact motion control applications requiring high efficiency and stable torque output.
| Nominal Voltage | 24 VDC |
| Rated Power | 25.4 W |
| Rated Speed | 5500 rpm |
| No-Load Current | 0.065 A |
| Stall Torque | 176 mNm |
| Friction Torque | 2.7 mNm |
| Torque Constant | 41 mNm/A |
| Current Constant | 0.024 A/mNm |
| Terminal Resistance | 5.5 ohm |
| Maximum Efficiency | 78 % |
| Operating Temperature Range | -30 to +125 °C |
| Attachment | FAULHABER (30/1) 011322 291 Planetary Gearhead |
| Gearhead Ratio | 3.71:1 |
| Gearhead Type | Precision Planetary Gearbox |
