HBM Z6FD1 50KG Load Cell
New
In stock1 unitReady to ship
Load Cell The HBM Z6FD1 50KG is a stainless steel load cell with 50 kg rated capacity, 2 mV/V sensitivity and IP68 protection for accurate industrial weighing.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
| Alternative Model | K-Z6 -F-D1-50-N-6-N-036-N |
| Part No. | 0001770667 000010 |
| Ser. No. | 31873398 |
| Ref. No. | 1770667 / 82202795 / 8500003490 |
| Nominal Rated Load (Emax) | 50 Kg |
| Nominal Voltage Range | 0.5 … 12 V |
| Nominal Sensitivity (Cn) | 2 mV/V |
| Input/Output Resistance | 350 … 480 O |
| Electrical Connection | Cable, PVC, 6-Wire |
| Material | Stainless Steel |
| Protection Class | IP68 |
| Operating Temperature | -10 … 40 °C |
| Diameter | 45 mm |
| Dimensions | 123 x 31 mm |
| Stock Key | CON003 |
| Condition | New |
| SKU | 1103736 |
| Weight | 1,25 |
