Hermetic CAM 1/4 Multistage Canned Refrigeration Motor Pump

Manufacturer: HERMETIC

Type: REFRIGERATION PUMP

Pump Model: CAM 1/4

Motor Model: AGX 1,0

MRN: 4110012622/011-01

Application: Refrigeration Pump, suitable for use with all refrigerant liquids.

Operating temperature: –50 … +30 °C

Fluid temp.: 0 … 3 °C

Impeller Diameter: 80 m

Voltage: 400 V

Rated Current: 2.7 A

Power: 1.5 kW

Frequency: 50 Hz

Pressure rating: 25 bar

Rotating speed: 2800 rpm

Capacity Q: 0.8 m3 / h when density: 1240, and Head: 33 m

Process connections: Flanged according DIN 2534, DN 20 and DN 25

Shaft: 1.4021

Protection: IP64/IP55

Dimensions (L * W * H):  475 X 160 X 210 mm

Weight: 29 Kg

Condition: Used
