Impac Infratherm IN 300 Digital Pyrometer
New
In stock1 unitReady to ship
Digital Pyrometer The IMPAC Electronic Infratherm IN 300 is a compact digital pyrometer for non-contact temperature measurement from -20 to 300°C, featuring 4 to 20 mA output and IP65 protection.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
| Part No. | 8356 330 |
| Ref. Nr. | 1805 |
| Temperature Ranges | -20 to 300°C |
| Power Supply | 24 VDC ± 25%, ripple 500 mV |
| Power Consumption | Max 0.6 W |
| Max Load | 500 O @ 24 V power supply |
| Connection Cable | 2 m length, fixed |
| Protection Class | IP 65 (DIN 40 050) |
| Ambient Temperature | 0 to 70°C |
| Housing | Stainless steel |
| CE Label | According to EU directives about electromagnetical immunity |
| Dimension | M25, Length 133 mm |
| Spectral Range | 8 to 14 µm |
| Measurement Uncertainty | 1.5% of measuring range Repeatability: 1% of measuring range |
| Optics 1 fixed optic | a = 100 mm |
| Exposure Time | t90 300 ms |
| Output | 4 to 20 mA |
| Stock key | CON003 |
| Condition | New |
| SKU | 1101092 |
| Weight | 0,33 |
