INA LR50/5-2RSR-HLC Yoke Type Track Roller
New
In stock2 unitsReady to ship
Yoke Type Track Roller The INA LR50/5-2RSR-HLC is a compact yoke type track roller with double-sided lip seals, designed for reliable guidance and smooth operation in industrial machinery.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
| Code | 3001V03 /0000220201/000429155-0000-14 |
| SN | 4054364591106 |
| Bore diameter d | 5 mm |
| Outer diameter D | 17 mm |
| Width B | 7 mm |
| Dynamic Load Capacity C | 1,690 N |
| Static Load Capacity C0 | 950 N |
| Effective fatigue limit load, radial | 50 N |
| Speed on permanent grease lubrication | 950 N |
| Permissible dynamic load, radial | 950 N |
| Sealing | 2RSR, Lip seal on both sides, with radial sealing action |
| Suffix | HLC, Factory Location Code |
| Diameter of thrust washer | 8.2 mm |
| Minimum chamfer dimension | 0.2 mm |
| Radius of outer ring outside profile | 500 mm |
| ITEM PER SET | 5 |
| Stock key | CON003 |
| Condition | New |
| SKU | 1101150 |
| Weight | 0,05 |
