INA ZKLF2575-2RS Axial Angular Contact Ball Bearing

Name: INA ZKLF2575-2RS AXIAL ANGULAR CONTACT BALL BEARING
SKU: 1030104
Availability: LimitedAvailability

ina-ZKLF2575-2RS-axial-angular-contact-ball-bearing-(used)

Used

Available on request

Manufacturer: Schaeffler INA Type: Axial Angular Contact Ball Bearing Model: ZKLF 2575 2RS Replaces: ZKLF 2575.2RS, ZKLF2575-2RS-XL

Manufacturer

INA?

SKU

1030104

Category

Thrust (Axial) Bearings

Condition

Used

25 Angular Axial Ball bearing bearings Contact Ina mm Schaeffler

Massive Inventory

Global Shipping

Expert Support

Quality Guaranteed

Manufacturer: Schaeffler INA
Type: Axial Angular Contact Ball Bearing
Model: ZKLF 2575 2RS
Replaces: ZKLF 2575.2RS, ZKLF2575-2RS-XL

Dimensions
Bore Diameter d: 25 mm
Outer diameter D: 75 mm
Width B: 28 mm
Chamfer r_min: 0.6 mm
Contact angle α: 60 °
Basic load ratings:
Dynamic C_r: 30500 N
Static C_0r: 55000 N
Fatigue load limit, axial: 3350 N
Limiting speed for grease lubrication: 5700 rpm
Thermally safe operating speed: 2600 rpm
Sealing: 2RS, Contact lip seal on both side
Operating Temperature: -30 … +120 °
