INA ZKLF2575-2RS-XL Axial Angular Contact Ball Bearing

Name: INA ZKLF2575-2RS-XL AXIAL ANGULAR CONTACT BALL BEARING
SKU: 983479
Availability: LimitedAvailability

ina-zklf2575-2rs-xl-axial-angular-contact-ball-bearing-1

ina-zklf2575-2rs-xl-axial-angular-contact-ball-bearing-2

ina-zklf2575-2rs-xl-axial-angular-contact-ball-bearing-3

New

Available on request

Manufacturer: Schaeffler INA Type: Axial Angular Contact Ball Bearing Model: ZKLF 2575 2RS XL Replaces: ZKLF 2575.2RS, ZKLF2575-2RS-XL

Manufacturer

INA?

SKU

983479

Category

Thrust (Axial) Bearings

Condition

New

25 Angular Axial Ball bearing bearings Contact Ina mm Schaeffler

Massive Inventory

Global Shipping

Expert Support

Quality Guaranteed

Manufacturer: Schaeffler INA
Type: Axial Angular Contact Ball Bearing
Model: ZKLF 2575 2RS XL
Replaces: ZKLF 2575.2RS, ZKLF2575-2RS
Dimensions
Bore Diameter d: 25 mm
Outer diameter D: 75 mm
Width B: 28 mm
Chamfer r_min: 0.6 mm
Contact angle α: 60 °
Basic load ratings:
Dynamic C_r: 30500 N
Static C_0r: 55000 N
Fatigue load limit, axial: 3350 N
Limiting speed for grease lubrication: 5700 rpm
Thermally safe operating speed: 2600 rpm
Sealing: 2RS, Contact lip seal on both side
Operating Temperature: -30 … +120 °
