Lapp AB-C3-M12Y-0.6PUR-M12FS-B Sensor/Actuator-Cable
New
In stock246 unitsReady to ship
Sensor/Actuator Cable
LAPP M12 sensor/actuator cable with 4-pin male to dual 4-pin female connectors, PUR sheath, 0.60 m length, IP65/IP67/IP68 protection, and UL/CSA certification for industrial automation.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
LAPP AB-C3-M12Y-0.6PUR-M12FS-B Sensor/Actuator Cable
The LAPP AB-C3-M12Y-0.6PUR-M12FS-B is a high-quality sensor/actuator cable designed for industrial automation environments requiring reliable signal transmission and durable performance. Featuring robust PUR outer sheath material and extra-flexible construction for drag chain applications, this cable ensures long service life under demanding conditions.
Manufacturer: LAPP
Type: Sensor/Actuator Cable
Model: AB-C3-M12Y-0.6PUR-M12FS-B
Item No.: 22260502
| Connector 1 | 4-Pins, Male |
| Connector 2 | 2 x 4-Pins, Female |
| Cable Connections | M12 Right-Hand Connector / 2 x M12 Right-Hand Socket |
| Number Of Poles | 3P |
| Length | 0.60 m |
| Outer Sheath Material | PUR |
| Sheath Color | Black |
| Flexibility | Extra-Flexible / For Chains |
| Nominal Voltage | 250 V |
| Cable Information | 300 V AC/DC “ 4 A, UL / cULus Listed, E249137 |
| Certification | UL / CSA |
| Kodierung | Coding A |
| Armored | No |
| Temperature Range | -25°C to +80°C |
| Type Of Protection | IP65 / IP67 / IP68 |
| Resistance | Oil, UV, Chemical, Acids, Lyes, Flame Retardant |
| Cable Type | M8Y | M12Y Sensor |
| Cable Subcategory | Sensor/Actuator Cables And M12/M8 Connectors |
