Schneider LC1D95P7 Contactor
New
In stock1 unitReady to ship
Contactor Schneider Telemecanique LC1D65AP7 TeSys Deca 3-pole contactor with a 230 V AC control circuit, rated up to 65 A AC-3, suitable for industrial motor control and resistive load applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
| Coil Model | LX1D6 P7 |
| Range | TeSys |
| Range of product | TeSys Deca |
| Product or component type | Contactor |
| Device short name | LC1D |
| Contactor application | Resistive load,Motor control |
| Control circuit voltage Uc | 230 V AC, 50/60 Hz |
| Rated operational voltage [Ue] | Power circuit: 690 V AC 25...400 Hz |
| Conventional free air thermal current [Ith] | 125 A |
| Motor power kW | 45 KW @ 400 V |
| Motor power hp | 60 hp @ 460 V |
| Poles description | 3 Poles |
| Pole contact composition | 3 Normally open contacts |
| Auxiliary contact composition | 1 Normally open + 1 Normally closed |
| Permissible ambient air temperature around the device | -40 … 60 °C |
| IP degree of protection | IP20 |
| Dimensions | 127 x 85 x 130 mm |
| Standards | EN 60947-4-1 |
| IEC 60335-2-40 | Annex JJ |
| UL 60335-2-40 | Annex JJ |
| IEC 60335-1 | Clause 30.2 |
| Condition | New |
| SKU | 1007599 |
| Weight | 1,56 |
