Schneider RE7RA11BU OFF-Delay Timing Relay

Schneider RE7RA11BU Off-Delay Timing Relay

The Schneider RE7RA11BU is an industrial off-delay timing relay designed for precise control in automation systems. It features a wide timing range and multiple supply voltage options, making it versatile for various applications.

Manufacturer: Schneider Electric

Type: Off-Delay Timing Relay

Model: RE7RA11BU

Technical Data:

• Product or Component Type: Industrial Timing Relay
• Component Name: RE7
• Discrete Output Type: Relay
• Contacts Material: 90/10 Silver Nickel
• Width Pitch Dimension: 22.5 mm
• Tightening Torque: 0.6 “ 1.1 N·m
• Maximum Switching Voltage: 250 V AC/DC
• Rated Supply Voltage [Us]:
  • 110“240 V AC 50/60 Hz
  • 24 V AC/DC 50/60 Hz
  • 42“48 V AC/DC 50/60 Hz
• Operating Temperature: -20 to 60 °C
• Pollution Degree: 3 (IEC 60664-1)
• Dielectric Strength: 2.5 kV
• Dimensions (H x W x D): 78 x 22.5 x 80 mm
