Schneider Zbrrd Programmable Receiver

Manufacturer: SCHNEIDER ELECTRIC

Type: PROGRAMMABLE RECEIVER

Model:  ZBRRD

Housing Material: Self-extinguishing plastic

Supply Voltage: 24 … 240 V AC/DC

Frequency: 50/60 Hz

Output type: 2 relays

output contacts: 2 C/O

No. Of Leds: 6

No. Of push buttons: 2

Input Output Isolation: Galvanic Isolation

Switching Capacity: 1250 VA

Maximum Switching Current: 5 mA AC/DC

Maximum Switching Voltage: 250 V AC/DC

Breaking Capacity: 15 W

Maximum Power Consumption: 4 W AC/DC

Reset time: 2 ms time delay

Transmission frequency: 2405 MHz

Protection Class: IP20

Temperature: -40…70 °C

Weight: 0.13 kg
