Seimec HFF 63B 4 B5 Brake Motor
Manufacturer: Seimec
Type: Brake Motors
Model: HFF63B4B5
Motor Speed [r/min]: 1360/1630
Motor Power [kW]: 0.18/0.22
Rated Voltage [V]: 230/277 Delta
Rated Voltage [V]: 400/480 Star
Nominal Current [A]: 1.26/0.73 Delta/Star
Motor Frequency [Hz]: 50/60
Cos Phi: 0.64
Thermal Class: F
Duty: S1
Protection Class [IP]: 54
Mounting Position [MI]: B5
Brake Model: FA02
Brake Torque [Nm]: 2/8
Brake Voltage [V]: 400/50
Brake Current [A]: 0.1
Weight [kg]: 6,6
