Sferax 815 Ubimo Linear Ball Bearing
New
In stock2 unitsReady to ship
Linear Ball Bearing SFERAX 815-UBIMO precision linear ball bearing with an 8 mm inner diameter, 15 mm outer diameter, 20 mm length, and four ball tracks. Designed for smooth and accurate linear motion in industrial automation applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
| Inner diameter d | 8 |
| Outer diameter D | 15 |
| Length | 20 mm |
| Tolerance Inner diameter | 0/+20 µm |
| Tolerance outer diameter | 0/-12 µm |
| Tolerance length | 0/-350 µm |
| Max. eccentricity | 15 µm |
| Recommended tolerance on the shaft | h6 |
| Dynamic load capacity | 297 N |
| Static load capacity | 420 N |
| Dynamic factor Y | 0.00303 |
| Diameter balls b | 2.000 mm |
| Cage material | DIN MS60Pb (17660) |
| Housing material | DIN 100Cr6 (1.3505) |
| Number of ball tracks | 4 |
| Operating temperature | -30 / +200°C |
| Stock key | CON003 |
| Condition | New |
