Siemens 3VA1112-3GF46-0AA0 Molded Case Circuit Breaker
New
In stock1 unitReady to ship
Molded Case Circuit Breaker The Siemens SENTRON 3VA1112-3GF46-0AA0 molded case circuit breaker features a 125 A current rating, four-pole design, operating voltage up to 690 VAC and 600 VDC, and high breaking capacity. It is designed to provide dependable line protection for industrial power distribution systems.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
| MNR | 3VA1112-3GF46-0AA0 |
| Product Brand Name | SENTRON |
| Insulation Voltage | 800 V |
| Operating Voltage | 600VDC/ 690VAC |
| Power Loss | 28,1W |
| Current | 125A |
| Number Of Poles | 4 |
| Frequency | 50/60 Hz |
| Rated Breaking Capacity (Icu) | (36kA / 220-240V AC), (25 kA / 380-415V AC) / (16 kA / 440V AC), (7 kA/ 690V AC) |
| Utilization Category | CAT.A |
| Frame | FRAME 160N |
| Field of Application | Line Protection |
| Arrangement Of Electrical Connectors | Front Terminal |
| Type Of Electrical Connection | Box Terminal On Both Sides |
| Number Of CO Contacts | 0 |
| Height | 130 mm |
| Width | 101.6 mm |
| Depth | 70 mm |
| Ambient Temperature | -25 to 70 °C |
| Standard | IEC/EN 60947-2, GB/T 14048.2 |
| Protection Degree | IP40 |
| Condition | New |
| Stock key | JO-004 |
| SKU | 1093338 |
| Weight | 1,38 |
