SKF Fytbk 30 TF Oval Flanged Ball Bearing Unit
New
In stock1 unitReady to ship
Flanged Bearing Unit
SKF oval flanged ball bearing unit with composite housing, steel bearing insert, and set screw locking, designed for reliable industrial shaft support.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
SKF FYTBK30TF Flanged Bearing Unit
The SKF FYTBK30TF is an oval flanged ball bearing unit designed for reliable shaft support and secure mounting in industrial applications. It features a composite housing combined with a steel bearing insert and set screw locking for stable operation and easy installation.
Manufacturer: SKF
Type: Oval Flanged Ball Bearing Unit With Set Screw Locking And Extended Inner Ring
Model: FYTBK30TF
Bearing No.: YAR 206-2F
Housing No.: FYTB 506 M
| Attachment Bolt Diameter | 10 mm |
| Shaft Diameter | 30 mm |
| Housing Overall Width | 33 mm |
| Centre Distance Between Bolt Holes | 116.5 mm |
| Bearing Width, Total | 38.1 mm |
| Basic Dynamic Load Rating | 19.5 kN |
| Basic Static Load Rating | 11.2 kN |
| Fatigue Load Limit | 0.475 kN |
| Limiting Speed | 6300 r/min |
| Housing Type | Flanged |
| Flanged Housing Type | Oval |
| Number Of Bolt Holes For Fasteners | 2 |
| Fastening Bolt Hole Type | Plain |
| Retaining Feature, Inner Ring | Set Screws |
| Bore Type | Cylindrical |
| Housing Material | Composite |
| Bearing Material | Steel |
| Lubricant | Grease |
