SKF NX 12 Z Combined Needle Roller / Angular Contact Ball Bearing
New
In stock3 unitsReady to ship
Combined Needle Roller / Angular Contact Ball Bearing
The SKF NX12Z Combined Needle Roller / Angular Contact Ball Bearing features a 12 mm bore diameter and a 21 mm outer diameter, providing superior load capacity and high-speed performance for demanding industrial applications.1221AngularBallbearingboreCombinedContactdiameterDynamicfatiguehigh-loadHigh-SpeedIndustrialLimitLoadmmNeedleNX12ZOuterRatingRollerSKFUnit
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
SKF NX12Z Combined Needle Roller / Angular Contact Ball Bearing
The SKF NX12Z Combined Needle Roller / Angular Contact Ball Bearing is a high-performance bearing designed for industrial applications requiring precise load handling and high-speed performance. This bearing combines the features of a needle roller and angular contact ball bearing, offering superior load capacity, reduced friction, and smooth operation.
Manufacturer: SKF
Type: COMBINED NEEDLE ROLLER / ANGULAR CONTACT BALL BEARING
Model: NX12Z
Basic Load Ratings:
Fatigue Load Limit:
Engineered for high-speed and high-load applications, the SKF NX12Z bearing ensures long-lasting performance and minimal maintenance in various industrial settings.
| Bore Diameter (d) | 12 mm |
| Outer Diameter (D) | 21 mm |
| Width (B) | 18 mm |
| Dynamic (Cr) | 5.39 kN |
| Static (C0r) | 5.2 kN |
| Basic Dynamic Load Rating, Axial | 5.27 kN |
| Basic Static Load Rating, Axial | 9.65 kN |
| Radial | 0.61 kN |
| Axial | 0.355 kN |
| Reference Speed | 8000 rpm |
| Limiting Speed | 5300 rpm |
