Step SYN 103-8932-6451 Stepping Motor

Manufacturer: StepSyn

Type: Stepping Motors

Model: 103-8932-6451

Basic Step Angle [°]: 1.8

Supply Voltage [V]: 12…300

Stall Torque [Nm]: 8.0

Bipolar Parallel Current [A]: 12.7

Unipolar Current [A]: 9.0

Resistance [Ω]: 0.28

Bipolar Holding Torque [Ncm]: 1330

Unipolar Holding Torque [Ncm]: 1020

Ambient Temperature [°C]: 40

Insulation Class: B

Protection Class [IP]: 43
