THK HSR30A1SS Linear Bearing Block
New
Available on request
Linear Bearing Block
The THK HSR30A1SS Linear Bearing Block is engineered for precision applications, featuring a flange-type block with a high load rating and advanced sealing system for superior performance.AutomationbearingbearingsBlockdurableFlangeGuidehigh-loadHSR30A1SSIndustrialLinearM10MachineMotionMountingPrecisionThk
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
THK HSR30A1SS Linear Bearing Block
The THK HSR30A1SS Linear Bearing Block is designed for precision motion applications, offering high load capacity, smooth linear motion, and enhanced durability. Featuring a flange-type block and advanced sealing system, it ensures optimal performance in demanding environments.
Manufacturer: THK
Type: Linear Bearing Block
Model: HSR30A1SS
Basic Load Ratings:
| Size | 30 |
| Length | 98 mm |
| Width | 90 mm |
| Height | 42 mm |
| Height of Block | 35 mm |
| Block Type | Flange |
| Dynamic Load Rating | 40.5 kN |
| Static Load Rating | 53.7 kN |
| Mounting Hole | M10 |
| Tapped Holes | 4 |
| Seal | 1SS, with End Seal, Side Seal, and Inner Seal |
