Vega Vegasel 441 B (444) Safety Temperature
Used
In stock1 unitReady to ship
299,99$
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Manufacturer: Vega
Type: Safety temperature limiter fixed
Model: VEGASEL 441 B (444)
Power supply: 20 … 250 V AC
Frequency: 48 … 62 Hz
Power consumption at Un: approx. 3 VA
Measuring signal input
Input voltage: 0 … 5 V
Connection line: 2-wire, unscreened (standard cable)
Resistance per conductor: max. 50 Ohms
Relay output
Contact: 1 SPDT
Function: two-point switching
Contact material: AgCdO and Au plated
max. turn-on voltage: 250 V AC
Current: 2 A
Power: 100 W
Netz voltage: 220 V AC
Housing type: plastic ABS
Ambient temperature: –25 … +60°C
Degree of protection: IP40
Dimensions: 96 x 76 x 102 mm
