Wago 750-502 2-CHANNEL Digital Output
Used
In stock2 unitsReady to ship
2-Channel Digital Output Module
The WAGO 750-502 provides two 24 V DC digital outputs with short-circuit protection, 2.5 kHz switching frequency, and a compact IP20 housing for automation systems.
New
In stock
This product is also available brand new
View New Version →
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
WAGO 750-502 2-Channel Digital Output Module
The WAGO 750-502 is a reliable 2-channel digital output module designed for precise switching tasks in automation systems. It provides stable 24 V DC output signals, short-circuit protection, and high switching frequency, making it ideal for industrial control applications.
Manufacturer: WAGO
Type: 2-Channel Digital Output
Model: 750-502
| Number of Digital Outputs | 2 |
| Total Number of Channels (Module) | 2 |
| Signal Type | Digital |
| Signal | 24 V DC |
| Actuator Connection | 2 x (2-wire, 3-wire, 4-wire) |
| Output Current | 2 A per channel, short-circuit protected |
| Switching Frequency | maximum 2.5 kHz |
| System Supply Voltage | 5 V DC via data contact |
| Short-Circuit Limitation (typical) | PWM 35 A |
| Isolation | 500 V |
| Inductive Load Switch-Off Energy Dissipation (maximum) | 0.14 J |
| Output Data Width (Internal) | maximum 2 bit |
| Incoming Power Jumper Contacts | 3 |
| Outgoing Power Jumper Contacts | 3 |
| Current Carrying Capacity (Power Jumper Contacts) | 10 A |
| Supply Voltage (System) | 5 V DC via data contacts |
| Current Consumption (5 V System Supply) | 3.5 mA |
| Operating Temperature | 0 to 55 degree Celsius |
| Housing Material | Polycarbonate, Polyamide 6.6 |
| Protection | IP20 |
| Dimensions | 100 x 70 x 62.6 millimeters |
| Operating Altitude | 0 to 2000 meters |
