Allen-Bradley 140M-C2E-C10 Ser.b Motor Protection
66,66$
Proteção do motor O dispositivo de proteção do motor Allen-Bradley 140M-C2E-C10 oferece proteção confiável contra sobrecarga e curto-circuito com alta capacidade de interrupção e ajustes de corrente ajustáveis para aplicações industriais.
Allen-Bradley 140M-C2E-C10 Motor Protection
The Allen-Bradley 140MC2EC10 Motor Protection device is a reliable solution for safeguarding motors against overloads, short circuits, and operational faults. Designed for demanding industrial environments, it ensures stable performance, high breaking capacity, and efficient protection across a wide current setting range.
Manufacturer: Allen-Bradley
Type: Motor Protection
Model: 140M-C2E-C10
| Rated Operating Voltage | 230 V AC |
| Rated Operational Current | 10 A |
| Power Loss | 6 W |
| Operating Frequency | 50 … 60 Hz |
| Sitting Range | 6.3 … 10 A |
| Magnetic Release Current | 195 / 130 A |
| Rated Service Breaking Capacity (Ics) | 415 V: 100 kA / 500 V: 50 kA / 690 V: 4 kA |
| Rated Short Circuit Breaking Capacity (Icu) | 415 V: 100 kA / 500 V: 50 kA / 690 V: 4 kA |
| Rated Impulse Voltage (Uimp) | 6 kV |
| Poles No. | 3-Pole |
| Type of Electrical Connection | Screw Connection |
| Dimensions | 45 x 74.5 x 90 mm |
