B&R 4PP3201505-31 POWER PANEL

Manufacturer: B&R

Type: Power Panel

Model: 4PP320.1505-31

Input voltage: 24 V DC

Input current: 0.4 … 1 A

Fuse voltage/Current: 125 V DC/10 A

Power consumption: Typ. 30 W

Display Diagonal: 15″ (381 mm)

Technology of Touch screen: Analog, resistive

Controller of Touch screen: Elo, serial, 12-bit

Interfaces: RS232

Operation temperature: 0 … 50 °C

Housing Material: Metal

Dimensions: 435 x 330 x 71.5 mm
