Crydom CSE2450 Solid State Relay
Manufacturer: CRYDOM
Type: Solid State Relay
Series: CSE
Model: CSE2450
Mounting Style: Panel Mount
Input Voltage: 15 … 32VDC
Load Current Rating: 50 A
Load Voltage Rating: 24 VAC to 280 VAC
Transient Overvoltage: 600 Vpk
Max. Surge Current, (16.6ms): 625 Apk
Max. On-State Voltage Drop @ Rated Current: 1.6 Vpk
Thermal Resistance Junction to Case: 0.63 ËšC/W
Max. Off-State Leakage Current @ Rated Voltage: 1.0 mA
Pd – Power Dissipation: 500 Mw
