Ericsson BML 901 367/1 Power System

Manufacture: Ericsson
Type: Power system
Model: BML901367/1
Part No.: UL 60950-1

Input Voltage: 172 … 275 V AC, (50-60 Hz)/Single phase ,(L,N, PE) or Two-phase (L, L, PE)Lightning protection 4 kA 10/350 μsDC
Input current: 12.5 A
Output: 48 V DC/3-phase
Output current: 16.3 A max.
Power: 2.3 kW
Cooling: Convection cooled
Protection degree: IP65
Mounting: Ericsson rail mounting
Temperature range: -40 … +60° C
Dimension (H x W x D): 310 x 90 x 290 mm
