FAG 6309.2ZR.C3 Deep Groove Ball Bearing
Rolamento de Esferas de Sulco Profundo FAG 6309.2ZR.C3 rolamento de esferas de sulco profundo com gaiola de aço, escudos metálicos sem contato em ambos os lados e folga C3 para aplicações industriais.
FAG 6309.2ZR.C3 Deep Groove Ball Bearing
The FAG 6309.2ZR.C3 deep groove ball bearing is designed for reliable radial and axial load handling in industrial applications. Manufactured by Schaeffler, this bearing features non-contact metal shields on both sides and C3 internal clearance for stable performance at higher operating speeds.
Manufacturer: FAG / Schaeffler
Type: Deep Groove Ball Bearing
Model: 6309.2ZR.C3
Replaces: 6309.2Z
For a complete solution, explore compatible industrial bearings and bearing accessories available in our Bearings category.
Please contact us via Ask for assistance with any inquiries.
| Bore Diameter (d) | 45 mm |
| Outer Diameter (D) | 100 mm |
| Width (B) | 25 mm |
| Dynamic Load Rating (Cr) | 56,000 N |
| Static Load Rating (C0r) | 31,500 N |
| Fatigue Load Limit | 2,240 N |
| Limiting Speed | 8,100 1/min |
| Reference Speed | 8,200 1/min |
| Cage | Steel Sheet Metal |
| Sealing | 2ZR, non-contact shield on both sides |
| Clearance | C3 |
