Festo 163366 50X125 ISO Cylinder
Novo
Em estoque4 unidadesPronto para envio
77,77$
Festo DNC-50-125-PPV-A-S10 ISO Cylinder The Festo DNC-50-125-PPV-A-S10 ISO Cylinder is a precision pneumatic actuator with a 50 mm bore, 125 mm stroke, and double-acting operation. Featuring adjustable pneumatic cushioning, durable aluminum construction, and operating pressure up to 12 bar, it is ideal for industrial automation and motion control applications.
ActingActuatorAirAutomationControlCylinderDNCDoubleFestoIndustrialISOLinearMotionpnPneumaticPneumatics
Grande Estoque
Envio Global
Suporte Especializado
Qualidade Garantida
| Part No. | 163366 |
| Code | H108 |
| Series | DNC |
| Fluid | Compressed Air |
| Stroke | 125 mm |
| Bore Size | 50 mm |
| Fram Dimensions | 64X265 mm |
| Rod diameter | 20 mm |
| Cushioning | Pneumatic cushioning, adjustable at both ends |
| Piston rod end | Male thread |
| Operating Mode | Double acting |
| Position detection | For proximity sensor |
| Variants | Piston rod at one end |
| Operating pressure | max. 12 Bar |
| Material cover | Die-cast aluminum, coated |
| Material seal | TPE-U(PU) |
| Material rod | High-alloy steel |
| Material cylinder barrel | Wrought aluminum alloy, smooth-anodized |
| Connection size | G1/4 |
| Ambient temperature | -20 to 80°C |
| Condition | New |
| Stock Key | JO-004 |
| SKU | 1097508 |
| Weight | 2,05 |
