Festo 2186 Toggle Lever Valve
Usado
Em estoque4 unidadesPronto para envio
TOGGLE LEVER VALVE
FESTO LS-3-1/8 / LOS-3-1/8 mechanical 3/2-way toggle lever valve with G1/8 connection, anodized aluminum body, and 146 l/min nominal flow rate.3/2-wayAirAluminumAnodizedconnectionFestoG1/8IndustrialLS-3-1/8MechanicalPneumaticPoppetSeatToggleValve
Grande Estoque
Envio Global
Suporte Especializado
Qualidade Garantida
FESTO LS-3-1/8 / LOS-3-1/8 TOGGLE LEVER VALVE
The FESTO LS-3-1/8 is a robust toggle lever valve engineered for mechanical actuation in compressed air systems. Its compact design and anodized aluminum body make it ideal for high-efficiency pneumatic applications requiring quick switching and reliable sealing performance.
Manufacturer: FESTO
Type: Toggle Lever Valve
Model: LS-3-1/8 / LOS-3-1/8
Part No.: 2186 / 2950
| Fluid | Air |
| Design | Poppet seat |
| Function | 3/2-way, closed, monostable |
| Type of Actuation | Mechanically |
| Operating Pressure | 3.5 ... 8 bar |
| Nominal Flow Rate | 146 l/min |
| Pneumatic Connection | G1/8 |
| Material | Anodized Aluminum |
| Ambient Temperature | -10 / 60 °C |
