Festo 8982 Toggle Lever Valve Body With Idle Return
Usado
Em estoque2 unidadesPronto para envio
TOGGLE LEVER VALVE
FESTO L-3-1/4-B toggle lever valve with idle return and 3/2-way function, designed for mechanical actuation in pneumatic systems.3/2-wayconnectionFestoG1/4IdleIndustrialL-3-1/4-BLeverMechanicalMonostablePneumaticPoppetReturnSeatToggleValve
Grande Estoque
Envio Global
Suporte Especializado
Qualidade Garantida
FESTO L-3-1/4-B TOGGLE LEVER VALVE WITH IDLE RETURN
The FESTO L-3-1/4-B toggle lever valve is engineered for reliable mechanical control in pneumatic systems. This 3/2-way, closed, monostable valve features robust aluminum die-cast construction and high flow capacity, making it ideal for industrial applications requiring precise mechanical actuation.
Manufacturer: FESTO
Type: Toggle Lever Valve with Idle Return
Model: L-3-1/4-B
Part No.: 8982
| Fluid | Air |
| Design | Poppet seat |
| Function | 3/2-way, closed, monostable |
| Type of Actuation | Mechanically |
| Operating Pressure | -0.95 ... 10 bar |
| Nominal Flow Rate | 600 l/min |
| Actuating Force | 24.5 N |
| Pneumatic Connection | G1/4 |
| Material | Aluminum die cast |
| Ambient Temperature | -10 / 60 °C |
