Festo DGPL-40-500-PPV-A-B-GF-GK-SH-D2 Linear Drive

Name: FESTO DGPL-40-500-PPV-A-B-GF-GK-SH-D2 LINEAR DRIVE
SKU: 971271
Availability: LimitedAvailability

festo-DGPL-40-400-PV-A-B-GF-GK-SH-D2-linear-actuator

festo-dgpl-40-400-pv-a-b-gf-gk-sh-d2-linear-actuator-1

festo-dgpl-40-400-pv-a-b-gf-gk-sh-d2-linear-actuator-2

festo-dgpl-40-400-pv-a-b-gf-gk-sh-d2-linear-actuator-3

Usado

Em estoque1 unidadePronto para envio

SKU

971271

Categoria

Pneumatic Actuators

Condição

Usado

40x500 Actuator Cylinder Drives Festo Linear N008 Pneumatic Rodless

Grande Estoque

Envio Global

Suporte Especializado

Qualidade Garantida

Manufacturer: FESTO

Type: Linear Drive

Model: DGPL-40-500-PPV-A-B-GF-GK-SH-D2

Part No: 175136

Materials

Cover: Coasted Cast Aluminum

Seals: NBR TPE-U(PU)

Piston Diameter: 40 mm

Cushioning: Adjustable at Both Ends

Stroke: 500 mm

Cushioning Length: 30 mm

Operating Pressure: 1.5…8 bar

Theoretical Force At 6 Bar, Retracting: 754 N

Theoretical Force At 6 Bar, Advancing: 754 N

Ambient Temperature: -10…60 °C

Pneumatic Connection: G1/4

Constructional Design: Pneumatic Linear Drive with Slide

Mode of Operation: Double-Acting

Guide: Recirculating Ball Bearing Guide

Position Sensing: For Proximity Sensor

Magnet: with Magnet

Type of Mounting: with Accessories

Weight: 7.78 kg
