Cables & Connectors Passive Junction Blocks

IFM AC5243 AS-Interface Airbox

Name: IFM AC5243 AS-INTERFACE AIRBOX
SKU: 1096804
Availability: LimitedAvailability






Usado

Em estoque1 unidadePronto para envio

AS-Interface Airbox The IFM AC5243 AS-Interface Airbox features 4 PNP digital inputs, 2×3/2-way function, and IP65/IP67 protection, operating with 26.5–31.6 V DC for reliable industrial automation.

Fabricante

IFM

SKU

1096804

Categoria

Passive Junction Blocks

Condição

Usado

AC5243 Airbox AS AS-i Automation Control Device Digital Electronic Fieldbus ifm Industrial Input Interface IO IP67 Module

Grande Estoque

Envio Global

Suporte Especializado

Qualidade Garantida

MRN	AirBox 2x3/2 4DI-Y IP67 AUX
Operating Voltage	26.5 / 31.6 V DC
Max. Current Consumption from AS-i	280 mA
Additional Voltage Supply	18 / 30 VDC
Max. Current Consumption from Additional Supply	10 mA
Number of Digital Inputs	4
Input Circuit of Digital Inputs	PNP
Power Supply	20/ 30 V
Function	2 x3/2 way
Max. Total Current Rating of Inputs	200 mA
Input Current High	6 / 10 mA
Input Current Low	0 / 2 mA
Ambient temperature[°C]	-10...55
Protection	IP 65; IP 67
Standard	EMC EN 50295/IEC 61000-6-2
Condition	Used
SKU	1096804
Weight	0,31
