Koyo TRD-2E100B Rotary Encoder

Manufacturer: KOYO

Type: Rotary Encoder

Model: TRD-2E100B

MNR: D7940444

Part No.: 101B00083

The KOYO TRD-2E100B rotary encoder is a high-performance sensor designed for accurate motion control and position detection in industrial automation systems. Its compact 40 mm outer diameter and robust construction make it ideal for installations with limited space and demanding environments.

Technical Specifications:

• Voltage Range: 10.8“26.4V DC
• Consumption Current (No Load): 50 mA or lower
• Output Form: NPN Open Collector Output
• Load Supply Voltage: 30 V DC or lower
• Shaft Allowable Load: Radial: 30N / Thrust: 20N
• Max. Allowable Number of Revolutions: 5,000 rpm
• Ambient Temperature Range: -10 to 70°C

This encoder ensures reliable feedback in automation systems and is particularly suited for use in textile machinery, robotics, and positioning devices.
