NSK 7008CTYNP5 Angular Contact Ball Bearing

Manufacturer: NSK
Type:  ANGULAR CONTACT BALL BEARING
Model: 7008 CTYNP5

Dimensions
Bore Diameter d: 40 mm
Outer diameter D: 68 mm
Width B: 15 mm
Contact angle: C, 15°
Cage: TY, Polyamide cage, guided by the inner ring
Design: N, Bearing with snap ring groove in the outer ring of the bearing
Tolerance Class: P5
Basic load ratings:
Dynamic C_r: 20.6 kN
Static C_0r: 15.9 kN
Limiting speed with Oil: 32500 1/min
Limiting speed with Grease: 21300 1/min
